Users Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
352
4.12.7 MED Port Setting
The Port LLDP MED Configuration/Port Setting Table screens in Figure 4-12-20 and Figure 4-12-21 appear.
Figure 4-12-20: Port LLDP MED Configuration Page Screenshot
The page includes the following fields:
Object Description
Port Select
Select port for this drop down list.
MED Enable
Enable or disable MED configuration.
MED Optional TVLs
Configures the information included in the MED TLV field of advertised
messages.
-Network PolicyThis option advertises network policy configuration
information, aiding in the discovery and diagnosis of VLAN configuration
mismatches on a port. Improper network policy configurations frequently result in
voice quality degradation or complete service disruption.
-LocationThis option advertises location identification details.
-InventoryThis option advertises device details useful for inventory
management, such as manufacturer, model, software version and other
pertinent information.
MED Network Policy
Select MED network policy for this drop down list.
Button
: Click to apply changes.
