User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
The page includes the following fields:
This is the logical port number for this row.
• Description
Click
to indicate the port name.
Display the current port state.
•
Display the current link status.
Display the current speed status of the port.
•
Display the current duplex status of the port.
• Flow Control
Configuration
Display the current flow control configuration of the port.
Display the current flow control status of the port.
4.3.2 Port Counters
This page provides an overview of traffic and trunk statistics for all switch ports. The Port Statistics screens in Figure 4-3-3,
Figure 4-3-4, Figure 4-3-5 & Figure 4-3-6 appear.
Figure 4-3-3: Port MIB Counters Settings Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port number for this drop down list.
• Mode
Select port counters mode.
Options:
All
Interface
Etherlike
