User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
374
4.14.4 Power over Ethernet Powered Device
3~5 Watts
Voice over IP phones
Enterprise can install POE VoIP Phone, ATA and other
Ethernet/non-Ethernet end-devices to the central where UPS is installed for
un-interrupt power system and power control system.
6~12 Watts
Wireless LAN Access Points
Museum, Sight
seeing, Airport, Hotel, Campus, Factory, Warehouse can
install the Access Point any where with no hesitation.
10~12 Watts
IP Surveillance
Enterprise, Museum, Campus, Hospital, Bank, can install IP Camera
without limits of install location – no need electrician to install AC sockets.
3~12 Watts
PoE Splitter
PoE Splitter split the PoE 52V DC over the Ethernet cable into 5/12V DC
power output. It frees the device deployment from restrictions due to power
outlet locations, which eliminate the costs for additional AC wiring and
reduces the installation time.
3~25 Watts
High Power PoE Splitter
High PoE Splitter split the PoE 52
V DC over the Ethernet cable into 24/12V
DC power output. It frees the device deployment from restric
tions due to
power outlet locations, which eliminate
the costs for additional AC wiring
and reduces the installation time.
30 Watts
High Power Speed Dome
This state-of-the-
art design is considerable to fit in various network
environments like traffic centers, shopping malls, rail
way stations,
warehouses, airports, and production facilities for the most demanding
outdoor surveillance applications- no need electrician to install AC sockets.
Since the GS-4210-16P2S and GS-4210-24P2S PoE Managed Switch per PoE port supports
52V DC PoE power output, please check and assure the Powered Device’s (PD) acceptable DC
power range is from 52V DC; otherwise, it will damage the Powered Device (PD).

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
