Users Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
329
4.11.4 Dynamic Learned
Dynamic MAC Table
Dynamic Learned MAC Table are shown on this page. The MAC Table is sorted first by VLAN ID, then by MAC address. The
Dynamic Learned screens in Figure 4-11-7 and Figure 4-11-8 appear.
Figure 4-11-7: Dynamic Learned Page Screenshot
The page includes the following fields:
Object Description
Port
Select port for this drop down list.
VLAN
Select VLAN for this drop down list.
MAC Address
Physical address associated with this interface.
Buttons
: Refreshes the displayed table starting from the "Start from MAC address" and "VLAN" input fields.
: Flushes all dynamic entries.
Figure 4-11-8: MAC Address Information Page Screenshot
