User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
4.2.5.2 SNTP Configuration
The SNTP Server Configuration screens in Figure 4-2-10 & Figure 4-2-11 appear.
Figure 4-2-10: SNTP Setup Page Screenshot
The page includes the following fields:
Object Description
• SNTP/NTP Server Address
Type the IP address or domain name of the SNTP/NTP server.
• Server Port
Type the port number of the server port.
Options:1-65535
Default: 123
Button
: Click to apply changes.
Figure 4-2-11: SNTP Server Information Page Screenshot
The page includes the following fields:
Object Description
• SNTP Server Address
Display the current SNTP server address.
• SNTP Server Port
Display the current SNTP server port.
