Planet GS-4210-24T2S User Manual

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
20
1.5 Product Specifications
Product
GS-4210-16T2S
GS-4210-24T2S
GS-4210-48T4S
Hardware Specifications
Hardware Version
1
1
2
10/100/1000T
Auto-MDI/MDI-X Copper ports
16 24 48
100/1000X SFP/mini-GBIC Slots
2
4
Console
One RS-232-to-RJ45 serial port (115200, 8, N, 1)
Reset Button
System factory default
Switch Architecture
Store-and-Forward
Switch Fabric
36Gbps/non-blocking
52Gbps/non-blocking
104Gbps/non-blocking
Switch Throughput@64 bytes
26.7Mpps @64 bytes
38.6Mpps @64 bytes
77.38Mpps @64bytes
MAC Address Table
8K entries
16K entries
Shared Data Buffer
4.1 megabits 12 megabits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
10K bytes
Reset Button
> 5 sec: Factory default
LED
System:
Power (Green)
10/100/1000T RJ45 Ports
(Port 1 to Port 16):
1000 LNK/ACT (Green),
10/100 LNK/ACT (Orange)
100/1000Mbps SFP Ports
(Port 17 to Port 18):
1000 LNK/ACT (Green),
100 LNK/ACT (
Orange
)
System:
Power (Green)
10/100/1000T RJ45 Ports
(Port 1 to Port 24):
1000 LNK/ACT (Green),
10/100 LNK/ACT (Orange)
100/1000Mbps SFP Ports
(Port 25 to Port 26):
1000 LNK/ACT (Green),
100 LNK/ACT (
Orange
)
System:
PWR(Power) (Green)
10/100/1000T RJ45 Ports
(Port 1 to Port 48):
1000 LNK/ACT (Green)
10/100 LNK/ACT (Orange)
100/1000Mbps SFP Ports
(Port 49 to Port 52):
1000 LNK/ACT (Green)
100 LNK/ACT (Orange)
Power Requirements
AC 100~240V, 50/60Hz, auto-sensing.
Power Consumption/
Dissipation
Max. 10.4 watts/35 BTU Max. 14 watts/47 BTU Max. 37.9 watts/129 BTU
Dimensions (W x D x H)
445 x 207 x 45 mm
440 x 330 x 44 mm
Weight
2kg 2.1kg 4.0kg
ESD Protection
Yes
Enclosure
Metal
Layer 2 Functions
Port Mirroring
TX/RX/Both
Many-to-1 monitor
VLAN
802.1Q tagged-based VLAN
Up to 256 VLAN groups, out of 4094 VLAN IDs

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
