User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
64
4.2.6 Log Management
The Managed Switch log management is provided here. The local logs allow you to configure and limit system messages that
are logged to flash or RAM memory. The default is for event levels 0 to 3 to be logged to flash and levels 0 to 6 to be logged to
RAM. The following table lists the event levels of the Managed Switch:
Level Severity Name Description
7 Debug Debugging messages.
6 Informational Informational messages only.
5 Notice Normal but significant condition, such as cold start.
4 Warning Warning conditions (e.g., return false, unexpected return).
3 Error Error conditions (e.g., invalid input, default used).
2 Critical Critical conditions (e.g., memory allocation, or free memory error - resource
exhausted).
1 Alert Immediate action needed.
0 Emergency System unusable.
4.2.6.1 Logging Service
The Managed Switch system local log information is provided here. The local Log screens in Figure 4-2-12 and Figure 4-2-13
appear.
Figure 4-2-12: Logging Settings Page Screenshot
The page includes the following fields:
Object Description
• Logging Service
Enabled: Enable logging service operation.
Disabled: Disable logging service operation.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
