User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
254
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• Mode (pps)
Display the current mode.
• Status (pps)
Display the current status.
• Periodic
Reauthentication
Display the current periodic reauthentication.
• Reauthentication
Period
Display the current reauthentication period.
• Quiet Period
Display the current quiet period.
• Supplicant Timeout
Display the current supplicant timeout.
• Max. EAP Requests
Display the current Max. EAP requests.
• Modify
Click
to edit 802.1X port setting parameter.
4.9.2.4 Guest VLAN Setting
Overview
When a Guest VLAN enabled port's link comes up, the switch starts transmitting EAPOL Request Identity frames. If the number
of transmissions of such frames exceeds Max. Reauth. Count and no EAPOL frames have been received in the meantime, the
switch considers entering the Guest VLAN. The interval between transmission of EAPOL Request Identity frames is configured
with EAPOL Timeout. If Allow Guest VLAN if EAPOL Seen is enabled, the port will now be placed in the Guest VLAN. If disabled,
the switch will first check its history to see if an EAPOL frame has previously been received on the port (this history is cleared if
the port link goes down or the port's Admin State is changed), and if not, the port will be placed in the Guest VLAN. Otherwise it
will not move to the Guest VLAN, but continue transmitting EAPOL Request Identity frames at the rate given by EAPOL
Timeout.
Once in the Guest VLAN, the port is considered authenticated, and all attached clients on the port are allowed access on this
VLAN. The switch will not transmit an EAPOL Success frame when entering the Guest VLAN.
While in the Guest VLAN, the switch monitors the link for EAPOL frames, and if one such frame is received, the switch
immediately takes the port out of the Guest VLAN and starts authenticating the supplicant according to the port mode. If an
EAPOL frame is received, the port will never be able to go back into the Guest VLAN if the "Allow Guest VLAN if EAPOL Seen"
is disabled.
The 802.1X Guest VLAN setting screens in Figure 4-9-11 and Figure 4-9-12 appear.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
