Planet GS-4210-24T2S User Manual

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
23
Product
GS-4210-16P2S
GS-4210-24P2S
Hardware Specifications
10/100/1000T
Auto-MDI/MDI-X Copper ports
16 24
802.3af/at PoE Injector Port
16
24
SFP/mini-GBIC Slots
Two 100/1000BASE-X SFP interfaces, supporting 100/1000Mbps dual mode
Console
One RS-232-to-RJ45 serial port (115200, 8, N, 1)
Reset Button
System factory default
Switch Architecture
Store-and-Forward
Switch Fabric
36Gbps/non-blocking
52Gbps/non-blocking
Switch Throughput@64 bytes
26.7Mpps @64 bytes
38.6Mpps @64 bytes
MAC Address Table
8K entries
Shared Data Buffer
4.1 megabits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
10K bytes
Reset Button
> 5 sec: Factory default
LED
System:
Power (Green)
10/100/1000T RJ45 Interfaces
(Port 1 to Port 16):
1000 LNK/ACT (Green),
10/100 LNK/ACT (Orange),
PoE (Orange)
100/1000Mbps SFP Interfaces
(Port 17 to Port 18):
1000 LNK/ACT (Green),
100 LNK/ACT (
Orange
)
System:
Power (Green)
10/100/1000T RJ45 Interfaces
(Port 1 to Port 24):
1000 LNK/ACT (Green),
10/100 LNK/ACT (Orange),
PoE (Orange)
100/1000Mbps SFP Interfaces
(Port 25 to Port 26):
1000 LNK/ACT (Green),
100 LNK/ACT (
Orange
)
Thermal Fan
2
Power Requirements
AC 100~240V, 50/60Hz, auto-sensing.
Power
Consumption/Dissipation
Max. 260 watts/886 BTU Max. 330 watts/1122 BTU
Dimensions (W x D x H)
440 x 208 x 44 mm (1U height) 445 x 207 x 45 mm (1U height)
Weight
2.8kg
ESD Protection
Yes
Enclosure
Metal
Layer 2 Functions
PoE Standard
IEEE 802.3af Power over Ethernet/PSE
IEEE 802.3at Power over Ethernet Plus/PSE
PoE Power Output
Per Port 52V DC, 300mA. Max. 15.4 watts (IEEE 802.3af)
Per Port 52V DC, 600mA. Max. 30 watts (IEEE 802.3at)
PoE Power Budget
300 watts
220 watts

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
