Planet GS-4210-24T2S User Manual

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
286
The page includes the following fields:
Object Description
• DMAC = SMAC
Enable or disable DoS check mode by DMAC = SMAC.
• Land
Enable or disable DoS check mode by land.
• UDP Blat
Enable or disable DoS check mode by UDP blat.
• TCP Blat
Enable or disable DoS check mode by TCP blat.
• POD
Enable or disable DoS check mode by POD.
• IPv6 Min Fragment
Enable or disable DoS check mode by IPv6 min fragment.
• ICMP Fragments
Enable or disable DoS check mode by ICMP fragment.
• IPv4 Ping Max Size
Enable or disable DoS check mode by IPv4 ping max size.
• IPv6 Ping Max Size
Enable or disable DoS check mode by IPv6 ping max size.
• Ping Max Size Setting
Set the max size for ping.
• Smurf Attack
Enable or disable DoS check mode by smurf attack.
• TCP Min Hdr Size
Enable or disable DoS check mode by TCP min hdr size.
• TCP-SYN (SPORT <
1024)
Enable or disable DoS check mode by TCP-syn (sport < 1024).
• Null Scan Attack
Enable or disable DoS check mode by null scan attack.
• X-Mas Scan Attack
Enable or disable DoS check mode by x-mas scan attack.
• TCP SYN-FIN Attack
Enable or disable DoS check mode by TCP syn-fin attack.
• TCP SYN-RST Attack
Enable or disable DoS check mode by TCP syn-rst attack.
• TCP Fragment
(Offset = 1)
Enable or disable DoS check mode by TCP fragment (offset = 1).
Button
: Click to apply changes.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
