User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
320
The page includes the following fields:
Object Description
• ACL Name
Select ACL name for this drop down list.
• Sequence
Set the ACL sequence.
• Action
Indicates the forwarding action of the ACE
 Permit: Frames matching the ACE may be forwarded and learned.
 Deny: Frames matching the ACE are dropped.
 Shutdown: Port shutdown is disabled for the ACE.
• Protocol
Specify the protocol filter for this ACE
 Any (IP): No protocol filter is specified.
 Select from list: If you want to filter a specific protocol with this ACE, choose
this value and select protocol for this drop down list.
• Source IP Address
Specify the Source IP address filter for this ACE
 Any: No source IP address filter is specified.
 User Defined: If you want to filter a specific source IP address with this ACE,
choose this value. A field for entering a source IP address value appears.
• Source IP Address
Value
When "User Defined" is selected for the source IP address filter, you can enter a
specific source IP address. The legal format is "xxxx:xxxx:xxxx:xxxx:
xxxx:xxxx:xxxx:xxxx". A frame that hits this ACE matches this source IP address
value.
• Source IP Prefix
Length
When "User Defined" is selected for the source IP filter, you can enter a specific
SIP prefix length in dotted decimal notation.
• Destination IP Address
Specify the Destination IP address filter for this ACE.
 Any: No destination IP address filter is specified.
 User Defined: If you want to filter a specific destination IP address with this
ACE, choose this value. A field for entering a source IP address value
appears.
• Destination IP Address
Value
When "User Defined" is selected for the destination IP address filter, you can
enter a specific destination IP address. The legal format is " xxxx:xxxx:xxxx:xxxx:
xxxx:xxxx:xxxx:xxxx ". A frame that hits this ACE matches this destination IP
address value.
• Destination IP Prefix
Length
When "User Defined" is selected for the destination IP filter, you can enter a
specific DIP prefix length in dotted decimal notation.
• Source Port
Specify the source port for this ACE.
 Any: No specifc source port is specified (source port status is "don't-care").
 Single: If you want to filter a specific source port with this ACE, you can
enter a specific source port value. A field for entering a source port value
appears. The allowed range is
0
to
65535
. A frame that hits this ACE

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
