User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
37
 Approved PLANET SFP Transceivers
PLANET Managed Switch supports both single mode and multi-mode SFP transceiver. The following list of approved PLANET
SFP transceivers is correct at the time of publication:
Gigabit SFP Transceiver Modules
 MGB-GT SFP-Port 1000BASE-T Module
 MGB-SX SFP-Port 1000BASE-SX mini-GBIC module
 MGB-LX SFP-Port 1000BASE-LX mini-GBIC module -10KM
 MGB-L30 SFP-Port 1000BASE-LX mini-GBIC module -30KM
 MGB-L50 SFP-Port 1000BASE-LX mini-GBIC module -50KM
 MGB-L70 SFP-Port 1000BASE-LX mini-GBIC module -70KM
 MGB-L120 SFP-Port 1000BASE-LX mini-GBIC module -120KM
 MGB-LA10 SFP-Port 1000BASE-LX (WDM,TX:1310nm) -10KM
 MGB-LB10 SFP-Port 1000BASE-LX (WDM,TX:1550nm) -10KM
 MGB-LA20 SFP-Port 1000BASE-LX (WDM,TX:1310nm) -20KM
 MGB-LB20 SFP-Port 1000BASE-LX (WDM,TX:1550nm) -20KM
 MGB-LA40 SFP-Port 1000BASE-LX (WDM,TX:1310nm) -40KM
 MGB-LB40 SFP-Port 1000BASE-LX (WDM,TX:1550nm) -40KM
Fast Ethernet SFP Transceiver Modules
 MFB-FX SFP-Port 100BASE-FX Transceiver -2KM
 MFB-F20 SFP-Port 100BASE-FX Transceiver -20KM
 MFB-F40 SFP-Port 100BASE-FX Transceiver -40KM
 MFB-F60 SFP-Port 100BASE-FX Transceiver -60KM
 MFB-FA20 SFP-Port 100BASE-BX Transceiver (WDM,TX:1310nm) -20KM
 MFB-FB20 SFP-Port 100BASE-BX Transceiver (WDM,TX:1550nm) -20KM
It is recommended to use PLANET SFP on the Managed Switch. If you insert an SFP
transceiver
that is not supported, the Managed Switch will not recognize it.
1. Before we connect Managed Switch to the other network device, we have to make sure both sides of the SFP
transceivers are with the same media type, for example: 1000BASE-SX to 1000BASE-SX, 1000Bas-LX to 1000BASE-LX.
2. Check whether the fiber-optic cable type matches with the SFP transceiver requirement.
 To connect to 1000BASE-SX SFP transceiver, please use the multi-mode fiber cable with one side being the male
duplex LC connector type.
 To connect to 1000BASE-LX SFP transceiver, please use the single-mode fiber cable with one side being the male
duplex LC connector type.
In the installation steps below, this Manual uses Gigabit SFP transceiver as an example. However
,
the steps for Fast Ethernet SFP transceiver are similar.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
