Planet GS-4210-24T2S User Manual

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
376
The Page includes the following fields:
Object Description
• Port
Select port for this drop down list.
• etherStatsDropEvents
The total number of events in which packets were dropped by the
probe due to lack of resources.
• etherStatsOctets
The total number of octets of data (including those in bad packets)
received on the network.
• etherStatsPkts
The total number of packets (including bad packets, broadcast
packets, and multicast packets) received.
• etherStatsBroadcastPkts
The total number of good packets received that were directed to the
broadcast address.
• etherStatsMulticastPkts
The total number of good packets received that were directed to a
multicast address.
• etherStatsCRCAlignErrors
The total number of packets received that had a length (excluding
framing bits, but including FCS octets) of between 64 and 1518 octets.
• etherStatsUnderSizePkts
The total number of packets received that were less than 64 octets.
• etherStatsOverSizePkts
The total number of packets received that were longer than 1518
octets.
• etherStatsFragments
The number of frames which size is less than 64 octets received with
invalid CRC.
• etherStatsJabbers
The number of frames which size is larger than 64 octets received with
invalid CRC.
• etherStatsCollisions
The best estimate of the total number of collisions on this Ethernet
segment.
• etherStatsPkts64Octets
The total number of packets (including bad packets) received that were
64 octets in length.
• etherStatsPkts65to127Octets
The total number of packets (including bad packets) received that were
between 65 to 127 octets in length.
• etherStatsPkts128to255Octets
The total number of packets (including bad packets) received that were
between 128 to 255 octets in length.
• etherStatsPkts256to511Octets
The total number of packets (including bad packets) received that were
between 256 to 511 octets in length.
• etherStatsPkts512to1023Octets
The total number of packets (including bad packets) received that were
between 512 to 1023 octets in length.
• etherStatsPkts1024to1518Octets
The total number of packets (including bad packets) received that were
between 1024 to 1518 octets in length.
Button
: Click to clear the RMON statistics.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
