User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
81
The page includes the following fields:
Object Description
• Server Address
Indicates the SNMP trap destination address. It allows a valid IP address in
dotted decimal notation ('x.y.z.w'). It can also represent a legally valid IPv4
address. For example, '::192.1.2.34'.
• SNMP Version
Indicates the SNMP trap supported version. Possible versions are:
 SNMP v1: Set SNMP trap supported version 1.
 SNMP v2c: Set SNMP trap supported version 2c.
• Notify Type
Set the notify type in traps or informs.
• Community Name
Indicates the community access string when send SNMP trap packet.
• UDP Port
Indicates the SNMP trap destination port. SNMP Agent will send SNMP message
via this port, the port range is 1~65535.
• Time Out
Indicates the SNMP trap inform timeout. The allowed range is 1 to 300.
• Retries
Indicates the SNMP trap inform retry times. The allowed range is 1 to 255.
Button
: Click to add a new SNMPv1, 2 host entry.
Figure 4-2-32: SNMPv1, 2 Host Status Page Screenshot
The page includes the following fields:
Object Description
• Server Address
Display the current server address.
• SNMP Version
Display the current SNMP version.
• Notify Type
Display the current notify type.
• Community Name
Display the current community name.
• UDP Port
Display the current UDP port.
• Time Out
Display the current time out.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
