User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
92
• ifOutDiscards
(Transmit Discards
Packets)
The number of inbound packets which were chosen to be discarded even though
no errors had been detected to prevent their being deliverable to ahigher-layer
protocol. One possible reason for discarding such a packet could be to free up
buffer space.
• ifInMulticastPkts
(Received Multicast
Packets)
The number of packets, delivered by this sub-layer to a higher (sub-) layer, which
were addressed to a multicast address at this sub-layer.
• ifInBroadcastPkts
(Received Broadcast
Packets)
The number of packets, delivered by this sub-layer to a higher (sub-) layer, which
were addressed to a broadcast address at this sub-layer.
• ifOutMulticastPkts
(Transmit Multicast
Packets)
The total number of packets that higher-level protocols requested betransmitted,
and which were addressed to a multicast address at this sub-layer, including
those that were discarded or not sent.
• ifOutBroadcastPkts
(Transmit Broadcast
Packets)
The total number of packets that higher-level protocols requested be transmitted,
and which were addressed to a broadcast address at this sub-layer, including
those that were discarded or not sent.
Figure 4-3-5: Ethernet link Counters Page Screenshot

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
