Planet GS-4210-24T2S User Manual

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
94
Figure 4-3-6: RMON Counters Page Screenshot
Object Description
• etherStatsDropEvents
The total number of events in which packets were dropped due to lack of
resources.
• etherStatsOctets
The total number of octets received and transmitted on the interface,
including framing characters.
• etherStatsPkts
The total number of packets received and transmitted on the interface.
• etherStatsBroadcastPkts
The total number of good frames received that were directed to the
broadcast address. Note that this does not include multicast packets.
• etherStatsMulticastPkts
The total number of good frames received that were directed to this
multicast address.
• etherStatsCRCAlignErrors
The number of CRC/alignment errors (FCS or alignment errors).
• etherStatsUnderSizePkts
The total number of frames received that were less than 64 octets
long(excluding framing bits, but including FCS octets) and were otherwise
well formed.
• etherStatsOverSizePkts
The total number of frames received that were longer than 1518
octets(excluding framing bits, but including FCS octets) and were otherwise
well formed.
• etherStatsFragments
The total number of frames received that were less than 64 octets in length
(excluding framing bits, but including FCS octets) and had either an FCS or
alignment error.

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
