User’s Manual of MGSW-28240F
30
1.5 Product Specifications
Product MGSW-28240F
Hardware Specification
SFP/mini-GBIC Slots
24 1000Base-SX/LX/BX SFP interfaces
(Compatible with 100Base-FX SFP Transceiver)
10Gbps Fiber Ports
4 1/10GBase-SR/LR SFP+ slots
Copper Ports
4 10/ 100/1000Base-T TP/SFP combo ports
Console Port
1 x RS-232 RJ45 serial port (115200, 8, N, 1)
Switch Processing Scheme
Store-and-Forward
Switch Throughput@64Bytes
95.2Mpps
Switch Fabric
128Gbps / non-blocking
Address Table
16K entries, automatic source address learning and ageing
Share data Buffer
16Mbits
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame
10Kbytes
Reset Button
< 5 seconds: System reboot
> 10 seconds: Factory Default
Dimensions (W x D x H)
440 x 200 x 44.5 mm, 1U high
Weight
2.935kg
LED
Power, DC1, DC2, Fault, Ring, R.O., Link/Act and speed per Gigabit port
Power Consumption
Max. 57 watts / 197.6BTU
Power Requirement – AC
AC 100~240V, 50/60Hz 1.5A
Power Requirement – DC
-36V DC @ 1.6A, Range: -36V ~ -72V DC
DI/DO
2 Digital Input (DI): Level 0: -24~2.4V (± 0.1V)
Level 1: 2.4~24V (± 0.1V)
Input Load Current: 10mA max.
2 Digital Output (DO): Open collector to 24VDC, 100mA max. load
Layer 2 Function
Port Configuration
Port disable / enable
Auto-Negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable / enable
Bandwidth control on each port
Power saving mode control
Port Status
Display each port’s speed duplex mode, link status, flow control status,
auto negotiation status, trunk status
VLAN
802.1Q Tagged based VLAN
Port-based VLAN
Q-in-Q
Private VLAN Edge (PVE)

Planet MGSW-28240F Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	56 Gbps
MAC Address Table	8K
Jumbo Frame	Up to 9K bytes
Weight	2.5 kg
Uplink Ports	4 x 1G SFP
Power Supply	Internal power supply, 100-240V AC, 50/60Hz
Power Consumption	20W
Operating Temperature	0 to 50 °C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Dimensions (W x D x H)	440 x 200 x 44 mm
Switch Architecture	Store-and-Forward
