User’s Manual of MGSW-28240F
<etype> : Ethernet Type: 0x600-0xFFFF or 'any' but excluding 0x800(IPv4) and 0x86DD(IPv6)
llc : LLC keyword
<dsap> : Destination Service Access Point: 0x00-0xFF or 'any'
<ssap> : Source Service Access Point: 0x00-0xFF or 'any'
<control> : LLC control: 0x00-0xFF or 'any'
snap : SNAP keyword
<pid> : Protocol ID (EtherType) or 'any'
ipv4 : IPv4 keyowrd
<protocol> : IP protocol number: (0-255, TCP or UDP) or 'any'
<sip> : Source IP address: (a.b.c.d/n) or 'any'
<dscp> : DSCP:(0-63,BE,CS1-CS7,EF or AF11-AF43)or'any',specific/range
<fragment> : IPv4 frame fragmented: yes|no|any
<sport> : Source TCP/UDP port:(0-65535) or 'any',specific or port range
<dport> : Dest. TCP/UDP port:(0-65535) or 'any', specific or port range
ipv6 : IPv6 keyowrd
<sip_v6> : IPv6 source address: (a.b.c.d/n) or 'any', 32 LS bits
<class> : QoS Class: "class (0-7)", default: basic classification
<dp> : DP Level: "dp (0-1)", default: basic classification
<classified_dscp>: DSCP: "dscp (0-63, BE, CS1-CS7, EF or AF11-AF43)"
QoS QCL Delete
Description:
Delete QCE entry from QoS Control list.
Syntax:
QoS QCL Delete <qce_id>
Parameters:
<qce_id>: QCE ID (1-256), default: Next available ID
Default Setting:
disable
Example:
Enable multicast storm control in 2fps
-28240F:/> QoS Storm multicast enable 2
