Planet MGSW-28240F - System Reboot

User’s Manual of MGSW-28240F
91
After the “Factory” button be pressed and rebooted, the system will be loaded default settings, except IP address.
To reset the Managed Switch
to the Factory default setting, you can also press the hardware reset button
at the front panel for about 5 seconds. After the device is rebooted, all configurations
will be loaded to
default settings to include IP address.
You can login the management WEB interface within the same
subnet of 192.168.0.xx.
4.2.23 System Reboot
The Reboot page enables the device to be rebooted from a remote location. Once the Reboot button is pressed, user will
re-access the WEB interface about 60 seconds later, the System Reboot screen in Figure 4-2-34 appears.
Figure 4-2-34: System Reboot Page Screenshot
Buttons
: Click to reboot the system.
: Click to return to the web main page without reboot the system.
