User’s Manual of SGSW-24040 / 24240 Series
1. INTRODUTION
The PLANET Layer 2 Managed Gigabit Switch series –SGSW Stackable, SGSW PoE and SGSW Fiber switch are all multiple
ports Gigabit Ethernet Switched with SFP fiber optical connective ability and robust layer 2 features; the description of these
models as below:
SGSW-24040 : 24-Port 10/100/1000Base-T with 4 Shared SFP Managed Stackable Switch
SGSW-24040R : 24-Port 10/100/1000Base-T with 4 Shared SFP Managed Stackable Switch / Redundant Power
SGSW-24040P 24-Port 10/100/1000Base-T PoE Managed Stackable Switch / 220W / IEEE 802.3af
SGSW-24040P4 24-Port 10/100/1000Base-T PoE Managed Stackable Switch / 380W / IEEE 802.3af
SGSW-24240 24-Port 100/1000Base-X with 8 Shared TP Managed Stackable Switch
SGSW-24240R 24-Port 100/1000Base-X with 8 Shared TP Managed Stackable Switch / Redundant Power
SGSW-24040HP 24-Port 10/100/1000 Base-T PoE Managed Stackable Switch / 360W / IEEE 802.3af/at
Terms of “Managed Switch” means the Switches mentioned titled in the cover page of this User’s manual, i.e. SGSW- series
Managed Switch.
1.1 Packet Contents
Open the box of the Managed Switch and carefully unpack it. The box should contain the following items:
Check the contents of your package for following parts:
The Managed Switch x1
User’s manual CD x1
Quick installation guide x1
19” Rack mount accessory kit x1
Power cord x1
Rubber feet X4
RS-232 DB9 male Console cable x1
CB-STX50 – 50cm stack cable x1
If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the carton including the
original packing material, and use them against to repack the product in case there is a need to return it to us for repair.
1.2 Product Description
Cost-effective IPv6 Managed Gigabit Switch solution for SMB
Nowadays, lots of electronic products or mobile devices can browse the Internet, which means the need of IP Address
