User’s Manual of SGSW-24040 / 24240 Series
314
2
Optional 3.84 to 6.49 Watts Low power
3
Optional 6.49 to 12.95 Watts (or to 15.4Watts) Mid power
4 Optional 12.95 to 25.50 Watts (or to 30.8Watts) High power
Table 4-16-1 Device class
Only SGSW-24040HP has IEEE 802.3at mode and supplies max. power up to 30.8 watts.
4.16.3 Port Configuration
This section allows the user to inspect and configure the current PoE port settings, screen in Figure 4-16-3 appears.
Figure 4-16-3 Power over Ethernet Configuration screenshot
