User’s Manual of SGSW-24040 / 24240 Series
77
• Receive Missing
Remote ID
The packets number that received packets which Remote ID option was missing.
• Receive Bad Circuit ID
The packets number that the Circuit ID option did not match known circuit ID.
• Receive Bad Remote
ID
The packets number that the Remote ID option did not match known Remote ID.
Client Statistics
Object Description
• Transmit to Client
The packets number that relayed packets from server to client.
• Transmit Error
he packets number that error sending packets to servers.
• Receive form Client
The packets number that received packets from server.
• Receive Agent Option
The packets number that received packets with relay agent information option.
• Replace Agent Option
The packets number that replaced received packets with relay agent information
option.
• Keep Agent Optin
The packets number that keepped received packets with relay agent information
option.
• Drop Agent Option
The packets number that dropped received packets with relay agent information
option.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page; any changes made locally will be undone.
: Clear all statistics.
