3D / SmartPan • 3D s / 3D Classic: 528 mm (20.7 in.)
• 3D Plus or 3D Mid with X-ray tube D-054SB /
3D Max with X-ray tube D-067SB: 600 mm
(23.6 in.)
• 3D Plus / 3D Mid / 3D Max with X-ray tube
D-059SBR or SXR 130-10-0.5 SC: 632 mm
(23.8 in.)
Magnification
Pan • 2D / 3D s / 3D Classic: 1.2-1.5
• 2D tomography: 1.5
• 3D Plus / 3D Mid: 1.4
SmartPan • 3D s / 3D Classic: 1.27
• 3D Plus / 3D Mid / 3D Max: 1.4
Ceph 1.13
3D • 3D s / 3D Classic: 1.58
• 3D Plus / 3D Mid / 3D Max: 1.38, 1.40, 1.42,
1.43 or 1.8
Duty cycle for height adjustment
25 s ON / 400 s OFF
Line voltage
100 - 220 V~ / 50 - 60 Hz
230 - 240 V~ / 50 Hz
Line current
8 - 17 A
Line harmonics
Cos better than 0.9
Max. permissible apparent impedance of supply mains
0.5 Ω (100 VAC)
Max. continuous heat dissipation
250 W
Internal fuse(s)
User replaceable 100 - 220 V~ / 16A FF H 500 V
230 - 240 V~ / 8A FF H 500 V
Type 195100 ELU
External fuse(s)
100 - 220 V ~ / 16A min. - 20A max. T 250 V
230 - 240 V ~ / 10A min. - 20A max. T 250 V
Battery
Lithium battery: CR2032, Varta / Panasonic
Max. weight
2D / 3D s / 3D Classic 119 kg (262 lb)
3D Plus / 3D Mid 141 kg (311 lb)
17 Technical data for Planmeca ProMax product family
User's manual Planmeca ProMax 97
