Plus C-20W - Appendix; Connections and Wiring Diagram

E-51
Appendix
Connections and Wiring Diagram
• Theconnectionsandwiringdiagrambelowisincludedhereforcheckingtheconnections.
[Captureboard and Printer Connections Diagram]
Computer
Captureboardfrontpanel
ToUSBport
ToPCdedicatedUSBport
USBcable(includedwithCaptureboard:3m)
ToPrinterconnector
ToDCINPUTconnector
USBcable(suppliedwiththeprinter)
ToUSBconnector
Printer
ToDCconnector
PrinterACpoweradapter
(suppliedwiththeprinter)
ACpoweradapter(supplied)
Towallpoweroutlet
* Appearanceofprinterisforillustrationpurposes.
Note
• TheAC power adapters of accessories and printers that havebeenverified to be operationmanydiffer from the ones
shownontheconnectionsdiagram(theymaybeofthebuilt-inormounted-ontype).
• When“Printfromcaptureboardprinter”inthecaptureboard’sdevicesettings(“CBSetup”)issetto“Enable”
Whenthecomputerandcaptureboardareconnected,youareaskedtoinstalltheprinterdriver.
UsetheCD-ROMincludedwiththeprinter,etc.,toinstalltheprinterdriveronthecomputer.
