Plus C-20W - Product Specifications; Board Physical Characteristics; Board Performance and Interface

E-50
BOARD TYPE (Model name) Standard (C-20S) Wide (C-20W)
Form
Installation method Self-standing (T-shaped legs), or wall mounting
External dimensions (T-shaped
legs*¹)
W1480 × D675 × H1947*² mm W1980 × D675 × H1947*² mm
Main unit weight 20 kg*³ 25 kg*³
T-shaped legs weight 12.5 kg
BOARD
Panel Size H910 × W1300 mm H910 × W1800 mm
Effective reading size H900 × W1280 mm H900 × W1780 mm
Number of Pages 2
Paging Endless in one direction (Horizontal scrolling)
Drive method Sheet movement
Reading method CIS (Contact Image Sensor)
Reading illumination light source RGB LED
Reading resolution
Main scanning direction (vertical sheet surface) 1.92 dots/mm (50 dpi or equivalent)
Sub scanning direction (horizontal sheet surface) 1.92 dots/mm (50 dpi or equivalent)
Reading time
Black & white: approx. 15 s
Color: approx. 15 s
Black & white: approx. 21 s
Color: approx. 21 s
Interface
Board
File format JPEG, PNG, PDF
Screen size
Standard type: Standard 864 × 1248 dots, High resolution 1728 × 2496 dots
Wide type: Standard 864 × 1728 dots, High resolution 1728 × 3456 dots
External
memory
Type USB Flash memory
Compatible FAT
types
FAT 16, 32
Interface USB1.1 or USB2.0 *
4
Network LAN port RJ-45 (10Base-T/100Base-TX)
Printing
Printing resolution 300 dpi or equivalent
No. print colors 16 or grayscale
Printer interface Conforming to USB 2.0 standards
Added functions
Clock Used for the timestamp and for file dating properties
PC connection Images can be acquired and device settings made via USB (using a browser)
Power supply
AC power adapter
Input : AC100–240V/50–60 Hz, Max 0.75 A
Output : DC 12 V, 3.0 A
Power consumption In standby: 3 W, During operation: 12 W (not including printer)
Operating
conditions
Temperature: 10–35°C
Humidity: 30–85% (No condensation)
Miscellaneous Miscellaneous Dedicated markers (black, red, blue, and green)
Operating
environment
OS
Fully IBM PC/AT compatible computer equipped with standard USB port
XP (Home Edition /Professional Edition, Service Pack 2 or greater)/
Vista (32-bit version)/Windows 7 (32- or 64-bit version)
Or, Apple Macintosh computer with standard USB port
Mac OS X 10.5 or greater
Web browser
Windows: Internet Explorer 8.0 or greater
Macintosh: Safari 5 or greater
* Enable JavaScript.
Remarks
*1: Theheightisadjustableat1747,1847and1947mm.
*2: Thevalueindicatedfor“H”(height)isthemaximumheight.
*3: Notincludingtheweightoftheprinter.
*4: USBmemorydevicenotincluded.Thememorycapacitycorrespondsto32GBorless.
• Pleasenotethatforqualityimprovementpurposes,specificationsanddesignaresubjecttochangewithoutpriornotice.
