Plus C-20W - Captureboard Functions; Basic Operations (Printing, Saving, Capturing); Networked Image Access

E-9
Basic Functions
① Printing ② Storing on USB memory
devices
③ Capturing images on a com-
puter
Network Functions
④ Viewing images stored on the captureboard
via a network
⑤ Viewing images stored on an FTP server via
a network
Functions specific to the captureboard
⑥ Combining images projected from a projec-
tor with hand-drawn data
⑦ Printing computer data on printer connect-
ed to board
Functions of the Captureboard
LAN
LAN
Outputtopaper
Viewing
ofimages
storedonthe
captureboard
Captureboard’s
memory
Projector
Viewingof
imagesstored
onFTPserver
Printer
Scanningwiththe
C-20Software
Combiningofimageoncomputerwithboard’shand-
drawndata
Printingofcombinedimageoncomputerfromprinter
connectedtocaptureboard
C-20Software’s
previewscreen
Storingon
USBmemory
device
Storingofimageoncomputer
Note
• Fordetailsonoperatingthe“PLUSC-20Software”andonconnectingtheequipment,seetheseparate“SoftwareOpera-
tionManual”.
