PMDG 737 0.00.63
INTRODUCTION
For Simulator Use Only DO NOT DUPLICATE NOVEMBER 2022
• CALL 1000: Here you can set 3 options for the 1000 ft call: YES
(always on), SMART (call will be made only if you are established
on an ILS glideslope), and NO (call will not be made).
• CALL 500: Here you can set 3 options for the 500 ft call: YES
(always on), SMART (call will be made only if you are established
on an ILS glideslope), and NO (call will not be made).
• CALL 400: Set the 400 ft call to ON or OFF.
• CALL 300: Set the 300 ft call to ON or OFF.
PAGE 6/16 – EGPWS 3
• CALL 200: Set the 200 ft call to ON or OFF.
• CALL 100: Set the 100 ft call to ON or OFF.
• CALL 50: Set the 50 ft call to ON or OFF.
• CALL 40: Set the 40 ft call to ON or OFF.
• CALL 30: Set the 30 ft call to ON or OFF.
PAGE 7/16 – EGPWS 4
• CALL 20: Set the 20 ft call to ON or OFF.
• CALL 10: Set the 10 ft call to ON or OFF.
• AIRSPEED LOW AURAL: Set the airspeed low alert to ON or
OFF. This option will be unavailable if LOW SPEED ALERT
(under the DISPLAY section) is set to OFF.
• TERRAIN PEAKS MODE: This setting allows alter the manner in
which the Enhanced Ground Proximity Warning System
(EGPWS) will display terrain on the navigation display. With
peaks mode active, the terrain display will continue to show you
the location and altitude of the highest terrain in the viewable
area of the display even if the aircraft is more than 2,000’ above
the highest terrain conflict based upon standard EGPWS
detection logic.
When not in peaks mode, EGPWS will remove display of terrain
related information when the airplane is more than 2,000’ above
the highest terrain in the viewable area based upon standard
EGPWS detection logic.
• SHOW WATER IN CYAN: This setting allows you to choose
whether sea-level bodies of water will appear in cyan on the ND’s
EGPWS terrain display.
