0.00.66 PMDG 737
INTRODUCTION
NOVEMBER 2022 DO NOT DUPLICATE For Simulator Use Only
PAGE 12/16 – INSTRUMENTS
• STANDBY INSTRUMENTS: This option allows you to decide
whether you want to have the ISFD, ISFD with RMI, or
SEPARATE standby instrument option installed. The ISFD
(Integrated Standby Flight Display) is an electronic, solid state
digital display that contains its own backup battery source of
power. The SEPARATE standby gauge configuration provides the
AI, ASI and ALT as separate instruments, as pictured below.
• HGS INSTALLED: This option allows you to decide if the Heads
Up Guidance System is installed in the flight deck of your 737.
The HGS system modeled in the PMDG 737 is fully functional,
fully collimated and provides an incredible improvement in
situational awareness during flight.
• HGS AUTO AIII MODE: This option determines whether your
HGS includes the Autoland AIII mode for use during instrument
approaches. The AIII mode improves pilot situational awareness
To Next Page
