• EFIS/MAP 80 KNOT BUG: Displays the 80 knot bug on the
airspeed indicator in EFIS/MAP mode.
• EFIS/MAP FPV: Displays the flight path vector on the attitude
indicator in EFIS/MAP mode.
PAGE 5/9 - ND
• TRACK UP: Alternate between a track-up navigation display and
a heading-up navigation display. The normal display used
throughout the industry is the track-up display as this provides
best situational awareness while operating in LNAV.
• VSD: Allow use of the Vertical Situation Display for terrain
awareness. (Press the CTR switch twice to display it.)
• RANGE ARCS: Display range arcs on the navigation display
when appropriate for the selected display mode.
• SHOW NEXT ALT CONSTR: Displays the next altitude crossing
constraint next to the waypoint on the ND without the DATA
switch on.
• VOR COURSE LINES: Display VOR course lines on the
navigation display as appropriate to navigation mode and
location.
PAGE 6/9 - ND
• MIN RUNWAY LENGTH: Airports with runways below this length
will not be shown on the ND.
• TCAS 3NM RANGE RING: Display 3nm range ring with TCAS.
• OTHER TRAFFIC: This toggle allows you to choose whether
TCAS only shows you proximate traffic (realistic) or shows you all
traffic in your vicinity. (Not realistic but convenient for online
flying!)
• RANGE: Allows you to manually change the display range for
TCAS traffic. (Useful for online fly-ins if you need to limit the
number of aircraft displayed on the screen.) We recommend
leaving this set to 40nm.
• ALT SEPARATION: Allows you to manually de-clutter traffic that
is above/below you. (Useful for online fly-ins if you need to limit
the number of aircraft displayed on the screen.) We recommend
leaving this set to 2800FT.
