POLA Xfarm - Zoom on Flap

10
C.1 F.1
See paragraph
VIEWING
3. Zoom on Flap path: Home>
Flap 1 ambient temperature (only when running in “natural” mode).
Flap 1 set temperature (only when running in “natural” mode).
Flap 1 %position (only when flap is controlled by freedback potentiomer or
by 0-10V).
Temperature
Temp. set
Position
Flap 1 (winter ventilation)
*Note: In the screenshot you only see the display options activated in “Configuration” (see par.D.C).
Flap 2 ambient temperature (only when running in “natural” mode).
Flap 2 set temperature (only when running in “natural” mode).
Flap 2
%position (only when flap is controlled by freedback potentiomer or by 0-
10V).
Temperature
Temp. set
Position
Flap 2 (summer ventilation)
Outdoor/indoor static
pressure difference
Variation set.
It is displayed only if it’s
not 0.0°. It means there
is a set conditioning.
Hit key F to display.
