POLA Xfarm User Manual

90
F. Check Control
F.9 Load cells
Path: Home>> Check Control> Load cells
This screen sums up the configuration of the load cells.
This is very useful at system start-up to check if extensions (TLC2-TLCO) and Xfarm were properly
connected.
F.8 0-10V outputs
Path: Home>> Check Control> 0-10V output
This screen sums up the configuration of the 0-10V outputs of the HXDA extensions.
This is very useful at system start-up to check if extensions (HXDA) were properly connected.
0.0V = 0.0v output
10.0V=10.0v output
1= Ventilation
2= Flap 1
3= Flap 2
4= Light
Dip-switch position on amplifier
TLC0 (Bird-weighing)
Dip-switch position on amplifier
TLC2 (silo weighing)
