3.56
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
REF.
DESCRIPTION NOTES
q
Screw Torque: 106 in-lbs (12 Nm)
Torque in sequence shown in this chapter.
w
Spark Plug
Assemble with dry threads.
e
Screw Torque: 89 in-lbs (10 Nm)
r
Screw Torque: 26 in-lbs (2.8 Nm)
t
Fuel Injector Apply P80 rubber lubricant prior to assembly.
y
T-MAP Sensor
Apply P80 rubber lubricant prior to assembly.
u
Intake Boot Apply P80 rubber lubricant prior to assembly.
i
Screw Torque: (22.5 Nm)
o
Screw Torque: 89 in-lbs (10 Nm)
a
Screw Torque: 89 in-lbs (10 Nm)
s
Starter Motor
Apply grease to starter o-ring.
d
Dipstick Apply engine oil to o-ring
ENGINE / COOLING SYSTEM
