10
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
10.9
DASH INSTRUMENTS / CONTROLS
REF.
DESCRIPTION NOTES
q
Instrument Cluster
w
Bezel
e
Key Switch
r
12V Accessory Plug
t
Turf Switch
y
Dash Panel
BODY / FRAME
