Polaris RANGER 570 2017 Service Manual

6.2
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION
TORQUE SPECIFICATIONS
ITEM
TORQUE VALUE
Bell Crank Nut
15 ft-lbs (20 Nm)
Differential Cover Screws
22 ft-lbs (30 Nm)
Park Flange Screws 8 ft-lbs (11 Nm)
Sector Gear Cover
11 ft-lbs (15 Nm)
Shift Cable Bracket Bolts
37 ft-lbs (50 Nm)
Shift Fork Screws
10 ft-lbs (14 Nm)
Snorkel Bearing Retaining Plate Screws 8 ft-lbs (11 Nm)
Snorkel Tube Locking Screw 8 ft-lbs (11 Nm)
Speed Sensor Screw 10 ft-lbs (14 Nm)
Transmission Case Screws
18 ft-lbs (24 Nm)
Transmission Fill / Drain Plugs 14 ft-lbs (19 Nm)
Transmission Rear Isolator Bolt
40 ft-lbs (54 Nm)
Transmission Rear Mount Bracket Fasteners
17 ft-lbs (23 Nm)
SPECIAL TOOLS, TRANSMISSION
PART NUMBER TOOL DESCRIPTION
PA-50231 Snorkel Tool
2871698 (Part of
2871702 Kit)
Rear Output Seal Driver
2871699 (Part of
2871702 Kit)
Rear Driveshaft Seal Guide
2871282
Bearing Seal Driver (50 mm)
PU-50566 Transmission Nut Socket
PU-50658 Clutch Center Distance Tool
Bosch Automotive Service Solutions: 1-800-345-2233 or http://polaris.service-solutions.com/
TRANSMISSION
