9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual

7.3

GENERAL INFORMATION

SPECIAL TOOLS

PART

NUMBER

TOOL DESCRIPTION

2872608 Roll Pin Removal Tool

PU-48951

or 8700226

CV Boot Clamp Tool

Bosch Automotive Service Solutions: 1-800-345-2233

or http://polaris.service-solutions.com

FINAL DRIVE TORQUE TABLE

ITEM SPECIFICATION

Brake Caliper Mount Bolt 46 ft-lbs (62 Nm)

Front Hub Castle Nut

90 ft-lbs (122 Nm)

Rear Hub Castle Nut

110 ft-lbs (150 Nm)

Prop Shaft Support

Bearing Fasteners

36 ft-lbs (49 Nm)

Prop Shaft Bearing Set

Screws

35 in-lbs (4 Nm)

Wheel Lug Nuts (Steel

Wheels)

36 ft-lbs (49 Nm)

Wheel Lug Nuts

(Aluminum Wheels)

30 ft-lbs + 90º (41 Nm +

90º)

FINAL DRIVE
