8
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
8.3
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
2870872
Shock Spanner Wrench
2870623
Shock Spring Compressor Tool
2876389 Multi-Function Pliers
2870871 Strut and Ball Joint Tool Set
2871573
Strut Spring Compressor (LH)
2871574
Strut Spring Compressor (RH)
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com/
Included in this machine’s tool kit, the multi-function
pliers is designed to remove the plastic push rivets used
to fasten body components.
STEERING / SUSPENSION
