9.28
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
5. Push caliper piston into caliper bore slowly with pads
installed.
NOTE
Brake fluid will be forced through compensating port
into master cylinder fluid reservoir when piston is
pushed back into caliper. Remove excess fluid from
reservoir as required.
6. Remove the brake pads.
BRAKE PAD INSPECTION
1. Check the brake pads for wear, damage, or
looseness.
2. Inspect the brake pad wear surface for excessive
wear.
MEASUREMENT
Brake Pad
.030″ (0.762 mm)
3. If any one pad is less than the service limit then all
pads should be replaced.
BRAKE SYSTEM
