11
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
11.9
INSTRUMENT CLUSTER
OVERVIEW
The instrument cluster displays critical vehicle information to the user. Reference the following page for display
functions and descriptions.
NOTE
Some features are not applicable to all models.
The use of a high pressure washer may damage the instrument cluster. Wash the vehicle by hand or with a garden
hose using mild soap. Certain products, including insect repellents and chemicals, will damage the instrument cluster
lens. Do not use alcohol to clean the instrument cluster. Do not allow insect sprays to contact the lens. Immediately
clean off any gasoline that splashes on the instrument cluster.
ELECTRICAL
To Next Page
