3.206
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
OIL PUMP REMOVAL
REF
DESCRPITION NOTES
q
Screw
w
Cover, Oil Pump
e
Washer
r
Pin, Solid
t
Shaft, Oil Pump
y
ASM., Gerotor
ENGINE / COOLING SYSTEM
