Polaris RANGER 570 2017 Service Manual

3
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
3.63
REF.
DESCRIPTION NOTES
Apply ENGINE OIL or WHITE LITHIUM grease to bearing
surfaces and/or bore.
Align gears to gear timing marks.
Crankshaft must be installed prior to seal installation.
u
Bearing
Apply ENGINE OIL or WHITE LITHIUM grease to bearing
surfaces and/or bore.
Install until bottomed in bore.
Bearings MUST rotate freely after assembly.
Apply load to outer race only.
i
Balance Shaft Apply ENGINE OIL or WHITE LITHIUM grease to bearing
surfaces and/or bore.
Align gears to gear timing marks.
IMPORTANT
Orient cir-clip as shown below. The gap should be located at the 6 o’clock or 12 o’clock locations.
IMPORTANT
Orient Piston as shown. Arrow should be pointing to the exhaust valve side.
ENGINE / COOLING SYSTEM
