570 ENGINE
DESCRIPTION TORQUE
Exhaust Shield Mounting Fasteners Torque until fully seated.
Flywheel Retaining Nut
133 ft-lbs (180 Nm)
Torque to specification, back of 180 degrees,
retorque to specification.
Camshaft Sprocket Bolt 14 ft-lb (19 Nm)
Replace camshaft sprocket bolt if loosened or
removed.
Intermediate Mag Cover 9 ft-lb (12 Nm)
Oil Filter
Lubricate seal with engine oil. Turn by hand until
filter gasket contacts sealing surface, then turn an
additional 3/4 turn
Oil Gallery Plug 11 ft-lbs (15 Nm)
Apply Loctite 516 sealant to first two thread under
plug head
Oil Pan Drain Plug 12 ft-lbs (16 Nm)
Oil Pickup 59.75 in-lbs (6.75 Nm )
Oil Pressure Regulator 20 ft-lbs (27 Nm)
Oil Pressure Regulator Valve Cover 8.8 ft-lbs (12 Nm)
Oil Pump Cover Bolts 7 ft-lbs (10 Nm)
Oil Pump Sprocket Bolt 9 ft-lbs (12 Nm)
One Way Clutch Retaining Bolts 9 ft-lbs (12 Nm)
Apply Loctite® 272™
Radiator hose clamp
36 in-lbs (4 Nm)
Stator Cover 9 ft-lbs (12 Nm)
Torque in Sequence
Spark Plug 9 ft-lbs (12 Nm)
Do Not Apply Anti-seize
Thermostat Cover Bolt 7.3 ft–lbs (10 Nm)
Starter Motor Bolts 7 ft-lbs (10 Nm)
Stator Wire Bracket Bolts 6 ft-lbs (9 Nm)
Apply Loctite® 242™
Stator Cover 9 ft-lbs (12 Nm)
Torque in Sequence
Valve Cover Bolts 7 ft-lbs (10 Nm)
Water Pump Cover Fastener 9 ft-lbs (12 Nm)
Torque in Sequence
NOTE: Refer to the diagrams and procedures within the chapter for fastener identification.
