3.130
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
REF.
DESCRIPTION NOTES
q
Piston Oil Jet Torque: 35 in-lbs (4 Nm)
w
Shoulder Bolt Torque: 88 in-lbs (10 Nm)
e
Screw Torque: 106 in-lbs (12 Nm)
r
Oil Pressure Regulator Assembly Torque: 20 ft-lbs (27 Nm)
t
Screw
IMPORTANT
Install oil pickup until fully in bore/hole prior to fastener
installation. Engine oil may be used to aid installation.
Torque: 35 in-lbs (6.75 Nm)
WARNING
DO NOT EXCEED TORQUE VALUE.
y
Screw Torque: 22 ft-lbs (30 Nm)
Replace if loosened or removed.
ENGINE / COOLING SYSTEM
