3.132
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
REF.
DESCRIPTION NOTES
q
Cylinder Apply ENGINE OIL to bottom 50 mm of cylinder bore and to piston
rings before assembly.
w
Cylinder Base Gasket Ensure tab is visible to verify assembly.
e
Piston Assembly
Apply ENGINE OIL to bottom 50 mm of cylinder bore and to piston
rings before assembly.
r
O-ring Ensure O-ring seals are seated in C’bores before assembly.
t
Straight Filter Adapter Torque: 20 ft-lbs (28 Nm)
y
Oil Filter Lubricate seal with engine oil prior to filter installation.
u
Screw Torque: 20 ft-lbs (28 Nm)
i
Plug
Torque: 11 ft-lbs (16 Nm)
o
Drain Plug
Torque: 11 ft-lbs (16 Nm)
a
Screw Torque: 106 in-lbs (12 Nm)
s
Screw Torque: 106 in-lbs (12 Nm)
d
Gear Sprockets to be installed so that “OUT” is visible.
f
Gear
g
Screw Torque: (12 Nm)
Replace if loosened or removed.
h
Oil Pump Cover Apply ENGINE OIL to bore of oil pump cover prior to assembly.
j
Gerotor Outer Gerotor dots must not be visible after assembly.
k
Gerotor Inner Gerotor Slot must be visible after assembly
ENGINE / COOLING SYSTEM
