3.138
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
REF.
DESCRIPTION NOTES
q
Spark Plug Do not apply Anti-Seize to threads prior to
assembly.
w
Valve Cover Isolator Apply P80 rubber lubricant prior to assembly.
e
Shoulder Bolt Torque: 89 in-lbs (10 Nm)
Torque in sequence show in this chapter.
Apply P80 rubber lubricant prior to assembly.
r
Screw Torque: 89 in-lbs (10 Nm)
t
Fuel Injector Apply P80 rubber lubricant prior to assembly.
IMPORTANT
Fuel injector O-rings should be replaced if a fuel
injector is removed or replaced.
Refer to the electronic parts catalog for the latest
part number.
y
Screw Torque: 26 in-lbs (2.8 Nm)
u
T-MAP Sensor Apply P80 rubber lubricant prior to assembly.
i
Intake Boot Apply P80 rubber lubricant prior to assembly.
o
Screw Torque: 89 in-lbs (10 Nm)
a
Screw Torque: 89 in-lbs (10 Nm)
s
Starter Motor
Apply grease to starter o-ring.
d
Dipstick Apply engine oil to o-ring
f
Hose Clamp Torque: 9 in-lbs (1 Nm)
g
Screw Torque: (22.5 Nm)
ENGINE / COOLING SYSTEM
