9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
3.141
IMPORTANT
Orient cir-clip as shown below. The gap should be located at the 6 o’clock or 12 o’clock locations.
IMPORTANT
Orient Piston as shown. “EX” should be nearest the exhaust.
IMPORTANT
Time balance shaft and crankshaft gears as shown.
ENGINE / COOLING SYSTEM
