9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
4.11
REF.
DESCRIPTION NOTES
q
Cover, Airbox
w
Seal, Cover
e
Airbox
r
Plug, Drain
t
Air Filter
y
Intake Boot
u
Clamp, Gear
i
Clamps, Gear Torque to 24 in-lbs (2.5 Nm)
o
Pre-Filter
a
Box, Intake
s
Plug, Drain
d
Screw Torque to 8 ft-lbs (11 Nm)
f
Seal, Engine, Inlet
g
Screw
h
Nut
Torque to 18 ft-lbs (27 Nm)
j
Hose - Breather
FUEL SYSTEM
