1.28
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
2018 RANGER 570 CREW
MODEL NUMBER:
R17RNA57A1
EPS: R17RNE57AM,
R17RNE57NM,
R17RNA57A9
CATEGORY DIMENSION / CAPACITY
Length
140″ / 355.6 cm
Width 60″ / 152.4 cm
Height 73″ / 185 cm
Wheel Base 105″ / 266.7 cm
Ground Clearance 10″ / 25.4 cm
Turning Radius
237″ / 602 cm
Dry Weight 1323 lbs. / 600 kg
1352 lbs. / 613 kg (W /
EPS)
Cargo Box Capacity 500 lbs. / 227 kg
Cargo Box Dimensions
(inside dimensions)
L- 42″ x W-32″ x H-11.5″
(107 x 81 x 29 cm)
Vehicle Payload
1250 lbs. / 567 kg
(Includes weight of
riders, cargo and
accessories)
Towing Capacity 1500 lbs. / 680.4 kg
Hitch Tongue Capacity 150 lbs. / 68 kg
GENERAL INFORMATION
