7
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
7.23
REF.
PART DESCRIPTION NOTES
1 ASM., GEARCASE, RH, ADC, 4WDC [INCL.
ALL]
2 ASM., COVER, OUTPUT
3
ASM., OUTPUT HUB
4
KIT, FASTENERS Torque: 8 ft-lbs (11 Nm)
5
KIT, SEAL REPAIR
6 PLATE, ARMATURE
7
PLATE, ARMATURE, BD
8
BEARING
9 KIT, ROLLER [SET OF 20]
10
ASM., ROLL CAGE [INCL. CAGE, 20 CLIPS]
11
ASM., GEARCASE
12 ASM., PLUG, DRAIN Torque: 11 ft-lbs (15 Nm)
13
PLUG, OIL FILL Torque: 8-10 ft-lbs (11-14 Nm)
14
RING, RETAINING, INTERNAL
15
KIT, SPRING
16
RING, RETAINING, EXTERNAL
17 ASM., GEAR HOUSING AND PINION GEAR
FINAL DRIVE
To Next Page
