Polaris RANGER 570 2017 Service Manual

8
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
8.5
REF
PART DESCRIPTION NOTES
q
ASM, TILT STEERING
w
WHEEL, STEERING
e
SHAFT, STEERING, UPPER / LOWER
r
ASM, GEAR BOX, STEERING
t
CAP, STEERING WHEEL
y
ASM, SHOCK, OIL LOCKING
u
BOLT
i
BOLT 40 ft-lbs (54 Nm)
o
SCREW
a
BOLT
s
NUT
d
NUT
16 ft-lbs (22 Nm)
f
NUT
40 ft-lbs (54 Nm)
g
NUT
36 ft-lbs (49 Nm)
h
NUT
65 ft-lbs (88 Nm)
j
BUSHING, STEERING
k
PIN, COTTER
l
LOCTITE® 271
STEERING / SUSPENSION
