10.6
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
NUMBER
PART DESCRIPTION
TORQUE (IF APPLICABLE)
Net Rod Mounts (Not Shown)
Screw (Used to fasten Net Rod Mounts) Torque to 8 ft-lbs (11 Nm)
2017 CREW CAB FRAME ASSEMBLY VIEW
BODY / FRAME
